Brand:    Elica
Colour:    Black
Dimensions (cm):    72x51,5x25
Energy Class:    A
Cut out (cm):    56x49
Total Absorption (kW):    7,4
Airflow Min Duct-Out (m³/h):    220
Airflow Max Duct-Out (m³/h):    500
Airflow Boost Duct-Out (m³/h):    620
Airflow Min Filtering (m³/h):    135
Airflow Max Filtering (m³/h):    420
Airflow Filtering (m³/h):    520
Airflow Min-Max (m³/h):    Duct-out: 250-850 | Filtering: 210-720
Suction Speed (m/s):    5,1
Noise Level Min-Max Aspiration (db(A)):    43 - 61
Noise Level Min-Max Filter (db(A)):    44 - 68
Controls - Extraction:    4S+B Slider touch control
Absorption (W):    160
Controls (Cooking):    9P+B slider touch control
Voltage (V):    220-240
Power Limitation (kW):    3,1 - 4,5
Number of Bridge Zones:    1 (SX)
Front Left Cooking Zone (kW):    OCTA 21x19,1 cm - 2,1/3
Right Front Cooking Zone (kW):    Ø 16 cm - 1,2/1,4
Rear Left Cooking Zone (kW):    OCTA 21x19,1 cm - 1,65/1,85
Rear Right Cooking Zone (kW):    Ø 20 cm - 2,3/3
Version:    This aspiration hob is available in a duct-out configuration but can be converted to a recycling one using the following kits, which are sold separately:
Elica Nikolatesla KIT0167757 Kit, Re-Circulation With Plinth Out
Elica Nikolatesla KIT0167756 Kit, Re-Circulation With Plinth In
Elica Nikolatesla KIT0167755 Ceramic Odour Filter Kit
Elica Nikolatesla KIT0180522 Kit, Re-Circulation With Back Outlet
