Brand:    Elica
Colour:    Black
Configuration:    This aspiration hob is available in a duct-out configuration but can be converted to a recycling one using the following kits, which are sold separately:
Elica Nikolatesla KIT0167757 Kit, Re-Circulation With Plinth Out
Elica Nikolatesla KIT0167756 Kit, Re-Circulation With Plinth In
Elica Nikolatesla KIT0167755 Ceramic Odour Filter Kit
Elica Nikolatesla KIT0180522 Kit, Re-Circulation With Back Outlet
Unique Features:    Bridge Zone | Comfort Silence | Autocapture | Super Easy Installation | Total Integration | Easy to Maintain | Delay Switch Off | Maintenance Alarm | Stop&Go | Child Lock | Timer | Warming Mode
Weight (Kg):    17
Dimensions (cm):    72 x 51 , 5 x 25
Cut Out (cm):    56 x 49
Energy Class:    A
Total Absorption (kW):    7,4
Airflow Min Duct Out (m3/h):    220
Airflow Boost Duct-Out (m3/h):    620
Number of Bridge Zones    1 (SX):
Airflow Max Filtering (m3/h):    420
Suction Speed (m/s):    5,1
Noise Level Min-Max Filter (db(A)):    44 - 68
Absorption (W):    160
Airflow Max Duct Out (m3/h):    500
Airflow Min Filtering:    135
Airflow Filtering:    520
Noise Level Min-Max Aspiration (db(A)):    43 - 61
Controls:    Extraction - 4S+B Slider Touch Control | Cooking - 9P+B Slider Touch Control
Voltage (V):    220-240
Power Limitation (kW):    3,1 - 4,5
Front Right Cooking Zone (kW):    Ø 16 cm - 1,2/1,4
Rear Right Cooking Zone (kW):    Ø 20 cm - 2,3/3
Left Front Cooking Zone (kW):    OCTA 21x19,1 cm - 2,1/3
Rear Left Cooking Zone (kW):    OCTA 21x19,1 cm - 1,65/1,85
